Microchip SY100ELT23LZG, Logic Level Translator, LVPECL to LVTTL, 8-Pin SOIC

Description

Maximum Low Level Output Current: 24mA

Dimensions: 4.93 x 3.94 x 1.48mm

Mounting Type: Surface Mount

Maximum Propagation Delay Time @ Maximum CL: 2.5 ns @ 3.3 V

Minimum Operating Supply Voltage: 3.135 V

Logic Function: Translator

Logic Family: ECL

Package Type: SOIC

Minimum Operating Temperature: -40 °C

Maximum Operating Supply Voltage: 3.465 V

Translation: LVPECL to LVTTL

Maximum Operating Temperature: +85 °C

Pin Count: 8 Maximum High Level Output Current: -3mA

This is Logic Level Translator LVPECL to LVTTL 8-Pin SOIC manufactured by Microchip. The manufacturer part number is SY100ELT23LZG. On the other hand, it is featured with 24ma of max. low level output current. The given dimensions of the product include 4.93 x 3.94 x 1.48mm. The product is available in surface mount configuration. It provides up to 2.5 ns @ 3.3 v maximum propagation delay time. While its minimum operating supply voltage is 3.135 v. The primary function of logic includes translator. The logic family is ecl. The package is a sort of soic. Whereas, the minimum operating temperature of the product is -40 °c. It has 3.465 v maximum operating supply voltage. It has a/an lvpecl to lvttl translation . It has a maximum operating temperature of +85 °c. It contains 8 pins. While a -3ma of maximum high level output current.
