KEMET PMR209MC6220M022R30

Description

Capacitance Tolerance: ±20%

Dimensions: 24 x 11.3 x 16.5mm

Mounting Type: Through Hole

Resistance Tolerance: ±30%

Series: PMR209

Operating Temperature Range: -40 °C → +85 °C

Length: 24mm

Height: 16.5mm

Capacitance: 220nF

Depth: 11.3mm

Voltage: 250 V ac, 630V dc

Minimum Operating Temperature: -40°C

Dielectric: Metallised Paper Number of Elements: 1 Maximum Operating Temperature: +85°C Resistance: 22Ω Center / Cutoff Frequency: – HTSUS: 8548.00.0000 RoHS Status: ROHS3 Compliant Attenuation Value: – Package / Case: Radial Type: Low Pass Voltage – Rated: 250VAC title: PMR209MC6220M022R30 REACH Status: REACH Unaffected edacadModel: PMR209MC6220M022R30 Models Applications: General Purpose Number of Channels: 1 edacadModelUrl: /en/models/3459489 Manufacturer: KEMET ESD Protection: No Size / Dimension: 0.945″ L x 0.299″ W (24.00mm x 7.60mm) Resistance – Channel (Ohms): 22 Values: R = 22Ohms, C = 0.22µF standardLeadTime: 13 Weeks Moisture Sensitivity Level (MSL): Not Applicable Mounting Type: Through Hole Series: PMR209 Operating Temperature: -40°C ~ 85°C Height: 0.551″ (14.00mm) Packaging: Bulk Filter Order: 1st Technology: RC Base Product Number: PMR209MC ECCN: EAR99

This ismanufactured by KEMET. The manufacturer part number is PMR209MC6220M022R30. It has ±20% capacitance tolerance . The given dimensions of the product include 24 x 11.3 x 16.5mm. The product is available in through hole configuration. It has the ability to tolerate resistance of ±30%. The product pmr209, is a highly preferred choice for users. The product has -40 °c → +85 °c of operating temperature range. Its accurate length is 24mm. In addition, the height is 16.5mm. It provides a 220nf of capacitance value. The product comes in 11.3mm depth. It carries a 250 v ac, 630v dc of voltage. Whereas, the minimum operating temperature of the product is -40°c. The dielectric options include metallised paper. It carries 1 elements. It has a maximum operating temperature of +85°c. It carries 22ω resistance. It is assigned with possible HTSUS value of 8548.00.0000. The product is rohs3 compliant. Moreover, the product comes in radial. It comes in low pass configuration. It also exhibits voltage rating of 250vac. In addition, it is reach unaffected. The product is widely employed in general purpose. It is supplied with 1 channels. The kemet’s product offers user-desired applications. ESD Protected – no. The product’s diameters include 0.945″ l x 0.299″ w (24.00mm x 7.60mm). Carreis the channel resistance of 22 ohms. Values include – r = 22ohms, c = 0.22µf . It has a long 13 weeks standard lead time. Its typical moisture sensitivity level is not applicable. The product has -40°c ~ 85°c operating temperature range. In addition, the height is 0.551″ (14.00mm). In addition, bulk is the available packaging type of the product. The filter is arrange in 1st order. This product use rc technology. Moreover, it corresponds to pmr209mc, a base product number of the product. The product is designated with the ear99 code number.
