EPCOS 4700μF Electrolytic Capacitor 400V dc, Screw Mount – B43455A0478M

Description

Diameter: 76.9mm

Ripple Current: 11A

Dimensions: 76.9 (Dia.) x 143.2mm

Mounting Type: Screw Terminal

Series: B43455

Equivalent Series Resistance: 41mΩ

Height: 143.2mm

Capacitance: 4700µF

Voltage: 400V dc

Minimum Operating Temperature: -25°C

Lifetime: 10000h

Maximum Operating Temperature: +85°C

Tolerance: ±20% Technology: Aluminium Electrolytic

This is 4700μF Electrolytic Capacitor 400V dc Screw Mount – B43455A0478M manufactured by EPCOS. The manufacturer part number is B43455A0478M000. Its diameter is 76.9mm. Furthermore, 11a is the ripple current. The given dimensions of the product include 76.9 (dia.) x 143.2mm. The product is available in screw terminal configuration. The product b43455, is a highly preferred choice for users. It has 41mω equivalent series resistance. In addition, the height is 143.2mm. It provides a 4700µf of capacitance value. It carries a 400v dc of voltage. Whereas, the minimum operating temperature of the product is -25°c. It provides a long-lasting service for a period of 10000h. It has a maximum operating temperature of +85°c. It features ±20% of tolerance value. This product use aluminium electrolytic technology.
