Description
BRITON 2003V Size 2-4Overhead Door Closer
Briton 2003V
The UK’s most popular adjustable power size EN 2-4overhead door closer. Internally testedto EN 1154 to over 1 million cycles for durability and reliability. Easy to fitand adjust to achieve low ‘opening force’ requirements for ease of access.
Witha 10 Year manufacturer’s guarantee, it meets the requirements of EN1154 and itis CE Marked. It is rated EN1634 fire tested at 2 hours for timber fire doorsand 4 hours for steel fire doors as well as being Certifire approved to CF111(please note that approval covers regular and transom applications only).
It isfully adjustable, with a strength size of 1 – 4 as well as fully adjustableclosing and latch action, with concealed adjustment to prevent unauthorisedtampering with the device. The 2003V closer is easy to install with reversiblehanding and backcheck and it is suitable for use with doors up to 80Kg and1100mm width.
Features
- Springadjustable power size EN 2-4 (EN 1-3 in parallel arm fixing)
- Certifiedfor door, frame mount and parallel applications
- Suitablefor doors up to 1100mm wide and 80kg
- Capableof meeting the requirements for BS8300
- Adjustableclosing speed & latch action
- Built-inadjustable backcheck to prevent damage to the door and frame
- Stylishflatform arm in finish to match door closer cover
- Universalfittings for Regular or Transom mount fixing
- Accufitself-adhesive fitting template for quick, accurate installation
- Suitablefor fire door applications
- Classicrobust cover conceals fixings and adjustment screws
- Optionalhold-open armset (for non-fire doors only)
- Availablein sprayed Silver finish all with matching arm and brackets
Certification
- UKCAMarked to EN 1154 (1121-CPR-UK-AD7600)
- CEMarked to EN 1154 (2812-CPD-AD0168)
- Testedto 1 million cycles to EN 1154 for durability and reliability in our accreditedtest facility
- CertifireApproved (CF111)
- Firetested to EN1634-1 on timber doors to achieve a 2 hour fire rating, and 4 hoursfor steal doors
- EnvironmentalProduct Declaration in accordance with ISO 14025 and EN 15804
Normal 0 false false false EN-US X-NONE X-NONE
Note: –>Specification Product InformationStandardsCE Marked, Certifire approved to CF111, EN1154 and EN1634Strength Size1 To 4Pack Quantity1PackagingBoxedWidth48mmApplicationFig 1, Fig 61, Fig 66Depth59mmFire Tested2 Hours Timber & 4 Hours MetalFinishSilver EnamelledHandedReversibleBackcheckYesWeight2.25KgBrandBritonGuarantee10 YearMax Door Width1100mmMax Door Weight80KgManufacturer Reference2003VLength249mm
