Bourns Inc. PTD901-1015K-B103

Description

HTSUS: 8533.40.8070

RoHS Status: ROHS3 Compliant

Termination Style: PC Pins, Board Locks

Temperature Coefficient: –

Number of Turns: 1.0

Power (Watts): 0.05W, 1/20W

Adjustment Type: Side Adjustment

Tolerance: ±10%

Resistance (Ohms): 10k

Actuator Length: 0.591″ (15.00mm)

title: PTD901-1015K-B103

Built in Switch: None

REACH Status: REACH Unaffected edacadModel: PTD901-1015K-B103 Models Resistive Material: Carbon edacadModelUrl: /en/models/3780988 Rotation: 300° Manufacturer: Bourns Inc. Taper: Linear Moisture Sensitivity Level (MSL): 1 (Unlimited) Actuator Diameter: 0.236″ (6.00mm) standardLeadTime: 14 Weeks Size – Body: Rectangular – 0.445″ x 0.374″ Face (11.30mm x 9.50mm) Features: – Mounting Type: Panel Mount Series: Pro Audio PTD90 Number of Gangs: 1 Packaging: Tray Bushing Thread: M7 x 0.75 Actuator Type: Knurled and Slotted Base Product Number: PTD901 ECCN: EAR99

Bourns Inc. PTD901-1015K-B103 is a linear panel mount potentiometer designed for precise control and adjustment in electronic circuits. This component, manufactured by Bourns Inc., stands out for its reliability and performance in various applications. With its linear taper, panel mount design, and durable construction, it provides engineers with a versatile solution for circuit adjustment and calibration needs.

Standout Features and Benefits of the PTD901-1015K-B103, Potentiometer

• Offers a standard resistance value suitable for a wide range of circuit requirements.
• Simplifies circuit design with a single potentiometer element.
• Provides a linear relationship between shaft position and resistance value.
• Facilitates easy installation and integration into control panels and enclosures.
• Ensures durability and stability over extended usage periods.
• Ideal for low-power applications, contributing to energy efficiency.
• Enhances mechanical stability on the PCB, reducing the risk of component displacement.
• Enables space-efficient PCB layout without compromising performance.

The Bourns Inc. PTD901-1015K-B103, Potentiometer: Versatile Usage

The Bourns Inc. PTD901-1015K-B103 potentiometer offers precise control and reliable performance, making it ideal for various electronic applications, including:

• Audio Equipment: Used for volume and tone control in amplifiers, mixers, and equalisers.
• Industrial Controls: Employed in machinery and equipment for precise parameter adjustment and calibration.
• Automotive Electronics: Integrated into dashboard controls, climate control systems, and infotainment interfaces.
• Instrumentation: Utilised in measurement instruments for calibration and sensitivity adjustment.
• Medical Devices: Incorporated into medical equipment for parameter control and monitoring.
• Consumer Electronics: Found in appliances, gaming consoles, and audio/video equipment for user interface control.
