Bourns 330 μH ±10% Ferrite Bobbin Core Power Inductor, 6.1A Idc, 74mΩ Rdc 1140

Description

Diameter: 1.5mm

Dimensions: 1.5 (Dia.) x 1.03mm

Lead Diameter: 0.051mm

Maximum DC Resistance: 74mΩ

Maximum DC Current: 6.1A

Series: 1140

Minimum Operating Temperature: -55°C

Height: 1.03mm

Core Material: Ferrite Bobbin Core

Inductance: 330 μH

Mounting Type: Radial

Lead Pitch: 1.15mm

Maximum Operating Temperature: +105°C Tolerance: ±10% Terminal Type: Radial Leaded

This is 330 μH ±10% Ferrite Bobbin Core Power Inductor 6.1A Idc 74mΩ Rdc 1140 manufactured by Bourns. The manufacturer part number is 1140-331K-RC. Its diameter is 1.5mm. The given dimensions of the product include 1.5 (dia.) x 1.03mm. Furthermore, the lead has 0.051mm diameter. It allows up to 74mω maximum DC resistance. While it carries 6.1a of maximum DC current. The product 1140, is a highly preferred choice for users. Whereas, the minimum operating temperature of the product is -55°c. In addition, the height is 1.03mm. The core is manufactured from highly durable and reliable ferrite bobbin core materials. The product has a 330 μh inductance value. The product is available in radial configuration. The lead features 1.15mm pitch. It has a maximum operating temperature of +105°c. It features ±10% of tolerance value. The terminal is a radial leaded type.
