Description
Race Width: 30.2mm
Outside Diameter: 85mm
Static Load Rating: 41.5kN
Partial Bearing Code: 3209
Number of Rows: 2
Inside Diameter: 45mm
Material: Steel
Bearing Clearance: CN
Ball Bearing Type: Double Row Angular Contact Ball Bearing
Bore Type: Parallel
Race Type: Plain
Cage Material: Non-metallic
Dynamic Load Rating: 52kN Bearing Series: 2 Light Sealing Arrangement: Both Sides Sealed Ball Material: Steel
This is Angular Contact Ball Bearing 45mm I.D 85mm O.D manufactured by SKF. The manufacturer part number is 3209 A-2RS1TN9/MT33. Whereas the race has a width of 30.2mm. The product has 85mm external diameter. It has 41.5kn static load rating. It comes in 2 of rows. Moreover, its inside diameter is 45mm. The product is made from highly stable and reliable steel. The double row angular contact ball bearing ball bearings last for a long time. The integrated bore is a type of parallel. Moreover, it has a plain type race . The cage is designed from highly rugged non-metallic material. It has 52kn dynamic load rating. Its ball is made up of [Plier Type] material .
