5 Volt Coil, SPDT Contacts, NO PIN 6, Fl

Description

Coil Voltage: 5V dc

Terminal Type: PCB Pin

Coil Resistance: 27Ω

Life: 1 x 10^7 cycles

Coil Power: 900mW

Isolation Coil To Contact: 6kV

Maximum Operating Temperature: +85°C

Switching Current: 15 A, 30A

Maximum Switching Current AC: 15 A, 30 A

Latching: No

Contact Configuration: SPDT

Depth: 27.5mm

Mounting Type: PCB Mount Series: HF165FD Length: 32.2mm Height: 20.4mm Maximum Switching Current DC: 30 A Maximum Switching Voltage AC: 277V Minimum Operating Temperature: -40°C Maximum Switching Power AC: 4.155 kVA, 8.31 kVA Number of Poles: 1 Contact Material: Silver Alloy

This is 5 Volt Coil SPDT Contacts NO PIN 6 Fl manufactured by Hongfa Europe GMBH. The manufacturer part number is HF165FD/5-ZY1TF. The coil voltage of the product is 5v dc. The terminal is a pcb pin type. It holds up to 27ω coil resistance. It is capable of doing 1 x 10^7 cycles in a lifetime . Robust coil power of 900mw. The product has 6kv isolation coil to contact. It has a maximum operating temperature of +85°c. It is integrated with 15 a, 30a switching current. It has a maximum 15 a, 30 a switching current AC . Latching Options – no. The contact is equipped with spdt configuration. The product comes in 27.5mm depth. The product is available in pcb mount configuration. The product hf165fd, is a highly preferred choice for users. Its accurate length is 32.2mm. In addition, the height is 20.4mm. It has a minimum 30 a DC switching current . It has a maximum AC switching voltage of 277v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 4.155 kva, 8.31 kva. It has equipped with 1 poles. The product is made from sturdy silver alloy materials.
