2 x 470 μH Wurth Elektronik WE-SL2 Common mode filter

Description

Maximum Current: 400 mA

Dimensions: 6 x 3.3 x 3.3mm

Mounting Type: Surface Mount

Voltage Rating: 80V

Series: WE-SL2

Operating Temperature Range: -40°C → +125°C

Termination Style: Surface Mount

Length: 6mm

Height: 3.3mm

Test Frequency: 1 KHz

Depth: 3.3mm

Inductance: 2 x 470 μH

Maximum Operating Temperature: +125°C Minimum Operating Temperature: -40°C DC Resistance: 2 x 0.35Ω

This is 2 x 470 μH WE-SL2 Common mode filter manufactured by Wurth Elektronik. The manufacturer part number is 744242471. It also carries 400 ma maximum current. The given dimensions of the product include 6 x 3.3 x 3.3mm. The product is available in surface mount configuration. Moreover, the product has a nominal 80v voltage rating. The product we-sl2, is a highly preferred choice for users. The product has -40°c → +125°c of operating temperature range. Moreover, it has surface mount terminal style. Its accurate length is 6mm. In addition, the height is 3.3mm. It features a test frequency of 1 khz. The product comes in 3.3mm depth. The product has a 2 x 470 μh inductance value. It has a maximum operating temperature of +125°c. Whereas, the minimum operating temperature of the product is -40°c. It has about 2 x 0.35ω DC resistance .
