1kΩ Through Hole Cermet Trimmer Resistor 0.5W Copal Electronics

Description

Shaft Diameter: 2.5 mm

Mounting Type: Through Hole

Maximum Operating Temperature: +120°C

Termination Style: Pin

Number of Turns: 15

Temperature Coefficient: ±100ppm/°C

Length: 19mm

Minimum Operating Temperature: -55°C

Power Rating: 0.5W

Maximum Resistance: 1kΩ

Tolerance: ±10%

This is 1kΩ Through Hole Cermet Trimmer Resistor 0.5W manufactured by Copal Electronics. The manufacturer part number is CT-20EP 1k Ohm. The diameter of the shaft is 2.5 mm. The product is available in through hole configuration. It has a maximum operating temperature of +120°c. Moreover, it has pin terminal style. Consist of 15 turns. It exhibits an excellent temperature coefficient of ±100ppm/°c. Its accurate length is 19mm. Whereas, the minimum operating temperature of the product is -55°c. Feature 0.5w of power rating. The product offers a maximum resistance up to 1kω. It features ±10% of tolerance value.
