10 mH Wurth Elektronik WE-FCL Common Mode Choke

Description

Dimensions: 37 x 26 x 45mm

Mounting Type: Through Hole

Maximum Current: 3.4 A

Series: WE-FCL

Operating Temperature Range: -40°C → +125°C

Termination Style: Solder Pad

Length: 37mm

Height: 45mm

Test Frequency: 10 KHz

Depth: 26mm

Inductance: 10 mH

Maximum Operating Temperature: +125°C

Minimum Operating Temperature: -40°C DC Resistance: 110mΩ

This is 10 mH WE-FCL Common Mode Choke manufactured by Wurth Elektronik. The manufacturer part number is 744866103. The given dimensions of the product include 37 x 26 x 45mm. The product is available in through hole configuration. It also carries 3.4 a maximum current. The product we-fcl, is a highly preferred choice for users. The product has -40°c → +125°c of operating temperature range. Moreover, it has solder pad terminal style. Its accurate length is 37mm. In addition, the height is 45mm. It features a test frequency of 10 khz. The product comes in 26mm depth. The product has a 10 mh inductance value. It has a maximum operating temperature of +125°c. Whereas, the minimum operating temperature of the product is -40°c. It has about 110mω DC resistance .
